Pre-configuring the HP Universal Print Driver (UPD) using the HP Driver Configuration Utility Video

Learn how to pre-configure the HP Universal Print Driver (UPD) using the HP Driver Configuration Utility (DCU) on a PC using Windows 7 32-bit operation system.
The DCU is an application used to edit the configuration file associated with a particular driver in order to change driver settings before installation.

A configuration file, which is part of the printer driver, maintains a set of default settings for the device once they are installed, the settings include; paper type, paper size, duplex settings, color options, and more.

For other helpful videos go to hp.com/supportvideos or youtube.com/hpsupport. More support options for your printer are available at hp.com/support.

This video was produced by HP.

---

Closed Caption:

In this training, we are going to walk you
through pre-configuring the HP Universal Print
Driver (HP UPD) using the
HP Driver Configuration Utility (DCU) on a
PC using the Windows 7 32-bit operating system.
This same process can be used on all operating
systems supported by the HP UPD.
HP DCU is a small Windows application used
to edit the configuration file associated
with a particular driver in order
to change driver settings before installation.
The configuration file controls the printer
driver settings and takes effect when the
driver is installed.
DCU can be used in all of the same environments
that the HP UPD supports.
DCU does not handle any part of the deployment
or installation of the driver.
The default configuration file is modified
and saved with the same name but as a .cfm
file.
DCU supports the following installation methods:
– First time driver installations sourced
from the driver package provided by HP.
– This includes running the installation
via:
• Add Printer Wizard
• HP UPD’s Install.exe
A configuration file, which is part of the
printer driver package, maintains a set of
default settings for the devices
once they are installed.
These settings include items like default
paper type, paper size, duplex setting, color
options, and more.
The DCU modifies the configuration file so
a new set of default values are presented
to the user during printing.
These settings can be locked in the event
that an administrator does not want these
values to change.
Depending on the process used, the digital
signature of the driver can be changed, which
can have an impact during
installation.
Please review all documentation prior to using
the HP DCU tool to get a complete understanding
of the process.
For this training, the following software
is required:
The HP Printer Administrator Resource Kit
(PARK)
– Version 1.6 is used in this training
The latest HP Universal Printer driver
– HP UPD PCL 6, version 5.5 is used in this
training
To download the driver and HP Printer Administrator
Resource Kit (PARK), open your browser and
go to www.hp.com/go/upd.
Click Download software.
Click HP Universal Print Driver for Windows.
Click the operating system you are using,
Microsoft Windows 7 (32-bit).
Scroll down and click Download, for the HP
Universal Print Driver for Windows PCL6.
Click Save.
Save the file to your computer.
Close the dialog.
Scroll down and click Download, for the HP
Printer Administrator Resource Kit.
Click Save.
Save the file to your computer.
Open the folder where the files were downloaded.
Double click the driver icon.
Uncheck the “When done unzipping, open install
file” box.
Click Unzip.
Click OK.
Click Close.
By default, the file is unzipped into the
directory on the C drive, in the HP Universal
Print Driver folder,
called pcl6-x32-5.5.0.12834.
This directory will vary based on the PDL
and driver version.
Click the park directory.
Click Extract all Files.
Select the directory where you want the files
extracted, in this case, the C drive.
Click Extract.
If not already open, double click the directory
to view all of the tools included in PARK.
Double click the Driver Configuration Utility
directory.
Double click the application “hpbcfgap”
to bring up the application.
Click OK to close the Information dialog.
Select File.
Select Open.
Browse to the driver folder and double click
the .cfg file.
Select the printing preferences or device
settings you wish to preconfigure. For example,
enable duplex by default.
Click on the drop-down menu.
Click True.
Now we’ll enable Job Storage by default.
Select the Job Storage Mode.
Click on the drop-down menu.
Select Personal Job.
Next, let’s modify a setting that is specific
to UPD, such as Status Notification Pop-ups.
Select the Device Settings tab.
Click on the Printer Status Notification drop-down
menu.
Select Disabled.
To complete the preconfiguring process, select
File.
Select Save As.
Use the same name as the original. cfg file,
but save it as a .cfm file.
Select the Desktop as the location to save
the file.
Click Save.
A new .cfm file will be created. Before installing
the UPD, this file must be copied to
the
Windows\System32\spool\drivers\w32x86\3 folder.
For 64-bit products, use the x64 folder.
Using this method will not invalidate the
digital signature from the driver. See the
HP System Administers Guide for
more information on this feature.
Close the HP DCU dialog box.
Right click the start button, and select Open
Windows Explorer.
Click the C drive.
Double click Windows.
Scroll down and double click System 32.
Scroll down and double click Spool.
Double click Drivers.
Double click w32x86.
Double click 3.
Copy or move the .cfm file to the 3 directory.
Click Continue.
Close the dialog.
Click Start and then click Devices and Printers.
Click Add a printer.
Click Add a local printer.
Click Create a new port.
Select Standard TCP/IP Port from the drop
down list.
Click Next.
Type in the IP address for your printer. This
can be found either on the control panel of
the printer or on the
Configuration page for the printer.
Make sure that "Query the printer and automatically
select the driver to use” is NOT selected.
Click Next.
Click Have Disk.
Click Browse to browse to the driver folder.
Browse to the driver.
With the .inf file listed in the File name
box, click Open.
Click OK.
Click the version specific driver.
Click Next.
Enter a printer name or use the default name.
Click Next.
Click Print a test page, to verify the printer
configuration.
Click Close.
After the test page prints, click Finish.
A pop up dialog appears showing the job is
stored on the printer as per the job storage
setting that was changed
in the DCU.
Click OK to close the dialog.
Right click on the new print queue, and click
Printing preferences.
Click the Finishing tab.
Note “Print on both sides” is checked
as per the pre-configuration settings.
Click the Job Storage tab.
Note “Personal Job” is selected as per
the pre-configuration settings.
Right click on the new print queue and click
Printer properties.
Click the Device Settings tab.
Note Printer Status Notification is disabled
as per the pre-configuration settings.
For more information on the Driver Configuration
Utility (DCU), see the readme file in the
driver configuration utility
directory.
For more information about the HP UPD including
information on different supported driver
installation methods and
driver pre-configuration tools, see the HP
Software Administrator’s Guide available
on www.hp.com/go/upd.
