Canopus ADVC-55 Analog to Digital Converter for MAC/PC - Input Only

Features
ADVC55 - High-quality Analog-to-Digital Video Conversion
Use ADVC55 to connect VHS, Hi8 and other analog video equipment to a DV camera, deck or editing system. ADVC55 is a compact and easy to use digital video converter compatible with Windows and Mac OS computers.

ADVC55 is ideal for capturing analog video into FireWire-equipped notebook and desktop editing computers. There are no drivers to install and ADVC55 does not require a power supply when used with a 6-pin DV cable.

Connects to all widely used DV and analog video equipment
Compatible with Windows and Mac OS DV editing systems
Compatible with leading editing and DVD authoring applications including Canopus EDIUS, Canopus Let's EDIT, Sonic Foundry® Vegas®, Final Cut Pro®, Avid Xpress® DV, Adobe® Premiere® Pro, Pinnacle Edition, Ulead Media Studio® Pro, and Windows Movie Maker
No need to install drivers or any software applications
Powered by IEEE 1394 (FireWire) connector*
NTSC and PAL compatible

* Using the 4-pin IEEE 1394 connector requires the ADVC55 AC Kit (sold separately)

Broad Compatibility
Broad video equipment and software compatibility ensures ADVC55 provides a long product life and a high return on investment.

Intelligent Input/Output
ADVC55's intelligent usability allows for easy setup and connection in any video environment. Automatic input signal detection and convenient front / back connectors ensure easy setup and operation.

Proven DV Codec Technology
At the heart of ADVC55 is Canopus 's proprietary DV codec chip providing the industry's best picture quality preservation during analog-to-DV conversion.

Specifications
ADVC55: Specifications
Package Contents:

* ADVC55 unit
* 1 x FireWire cable (6-pin 6-pin)
* User manual


ADVC-PSU5V AC Adaptor Kit*

* 1 x AC power adapter
* 1 x FireWire cable (6-pin 4-pin)

*ADVC-PSU5V Adaptor Kit sold separately.
Note: Use of other power supplies for ADVC55 operation is not recommended and will void warranty.


Technical Specifications:
Video Formats

* NTSC: 720x480 @ 29.97fps
* PAL/SECAM: 720x576 @ 25fps

Audio Formats

* 2-channel 48kHz 16-bit

Digital Video Output

* 1 x 6-pin FireWire (100Mbps)

Analog Video Input

* 1 x S-Video (4-pin miniDIN)
* 1 x composite (RCA)

Analog Audio Input (unbalanced)

* 1 x stereo (RCA)

Power Source

* IEEE 1394 bus powered or DC5V from EIAJ#2 DC jack

Power Usage

* 3.1W


ADVC-PSU5V AC Adaptor Kit* Technical Specifications:
Power Input

* DC5V

Power Supply

* DC5V AC Adapter AC100V/220V

*ADVC-PSU5V Adaptor Kit sold separately.
Note: Use of other power supplies for ADVC55 operation is not recommended and will void warranty.


Minimum System Requirements:
Windows PC

* Windows® 2000 (requires Service Pack 3 or higher), Windows® XP Home or Windows® XP Professional (requires Service Pack 1 or higher)
* DirectX 8.0 or higher

Mac

* Mac OS X (10.2.7/10.2.8/10.3)

Note: A video capture card or OHCI FireWire connection is required to capture DV.

---

Closed Caption:

the canopius a BBC 55 the ATV c55 is a
capture only no output analog-to-digital
converter is used to capture analog
video sources such as VHS hi-8 another
dexon cameras with no DVI port into your
computer via its firewire connection the
advc 55 features one s-video port one
composite video port as well as analog
stereo left and right audio input ports
those are all RCA connectors on the rear
is one 6-pin firewire port that connects
your computer next to that is the power
port for optional power adapter ABC 55
works on both mcintosh including the new
leopard and on PCs including the new
windows vista and works with any editing
and capture software that supports DV
also called firewire input this
converter and other canopius converters
feature a vsync lock that means that
when you capture your audio video sink
will not end up looking like a bad come
full movie and for those of you who need
pal video support it's got that too its
portable enough to travel with his great
device for laptops it could be powered
by 6-pin firewire port or if your
computer does not have won an optional
power adapter not sure which port you
have well most pc laptops have a 4-pin
firewire port almost desktops have a
6-pin port on mac laptops and desktops
they typically include a 6-pin firewire
port
another great feature is its
plug-and-play so there are no pesky
drivers to install to get setup all you
need to do is plug it in
connect your video source and start
capturing so for those of you looking
for a high-quality low-cost input only
device that will preserve your precious
original video
this is the best choice and since it's
made by campus it's backed by one of the
most trusted names in video conversion
products
